Typical Applications: Printer, Copy Machine, Sewing Machine, Water Pump, Hair Dryer, Circular Saw, String Trimmer, etc.
High efficiency, less noise, and low current, 24V DC motor.
Can match with 45mm planetary gearbox, or 51mm gearbox.
Shaft: 5.0mm diameter, shaft length 14.5 / 19.5mm.
Mounting Holes: 2-M4.0 x 0.7.
Double shaft for encoder, 12ppr.
Samples can be provided for your test.
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OPERATING RANGE | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
| V | rpm | A | rpm | A | mN.m | g.cm | w | mN.m | g.cm | A | |||
| TRS-775PM | 2765 | 6.0-30.0 | 24.0 | 7600 | 0.37 | 5810 | 0.22 | 73.53 | 750 | 44.7 | 312.35 | 3186 | 8.23 |
| 4045 | 6.0-15.0 | 12.0 | 4600 | 0.60 | 3500 | 4.30 | 84.31 | 860 | 36.6 | 352.94 | 3600 | 16.1 | |
These motors are widely used in commercial and household appliances, including printers, copy machines, sewing machines, water pumps, hair dryers, circular saws, and string trimmers.
Yes, both the RS-555 and RS-775 DC motors are designed to easily pair with standard gearboxes, specifically 45mm planetary gearboxes or 51mm gearboxes, depending on your torque and speed requirements.
The operating voltage range spans from 6.0V to 30.0V DC. Common nominal voltage configurations include 12V and 24V, matching various power supply setups.
Yes, these motors can be equipped with a double shaft to accommodate encoders (such as a 12ppr encoder) for precise speed and position control.
The standard shaft diameter is 5.0mm, with available shaft lengths of 14.5mm and 19.5mm to fit different mounting configurations.
Yes, samples can be provided for evaluation and testing to ensure the motor performance matches your application requirements before committing to bulk purchases.
